The One Problem with the VCSA

Over the past couple of months I noticed a trend in my top blog daily reporting…the Quick fix post on fixing a 503 Service Unavailable error was constantly in the top 5 and getting significant views. The 503 error in various forms has been around since the early days of the VCSA which usually manifests it’s self with the following.

503 Service Unavailable (Failed to connect to endpoint: [N7Vmacore4Http20NamedPipeServiceSpecE:0x0000559b1531ef80] _serverNamespace = / action = Allow _pipeName =/var/run/vmware/vpxd-webserver-pipe)

Looking at the traffic stats for that post it’s clear to see an upward trend in the page views since about the end of June.

This to me is both a good and bad thing. It tells me that more people are deploying or migrating to the VCSA which is what VMware want…but it also tells me that more people are running into this 503 error and looking for ways to fix it online.

The Very Good:

The vCenter Server Appliance is a brilliant initiative from VMware and there has been a huge effort in developing the platform over the past three to four years to get it to a point where it not only became equal to vCenter’s deployed on Windows (and relying on MSSQL) but surpassed it in a lot of features especially in the vSphere 6.5 release. Most VMware shops are planning to or have migrated from Windows to the VCSA and for VMware labs it’s a no brainer for both corporate or homelab instances.

Personally I’ve been running VCSA’s in my various labs since the 5.5 release, have deployed key management clusters with the VCSA and more recently have proven that even the most mature Windows vCenter can be upgraded with the excellent migration tool. Being free of Windows and more importantly MSSQL is a huge factor in why the VCSA is an important consideration and the fact you get extra goodies like HA and API UI’s adds to it’s value.

The One Bad:

Everyone who has dealt with storage issues knows that it can lead to Guest OS file systems errors. I’ve been involved with shared hosting storage platforms all my career so I know how fickle filesystems can be to storage latency or loss of connectivity. Reading through the many forums and blog posts around the 503 error there seems to be a common denominator of something going wrong with the underlying storage before a reboot triggers the 503 error. Clicking here will show the Google results for VCSA + 503 where you can read the various posts mentioned above.

As you may or may not know the 6.5 VCSA has twelve VMDKs, up from 2 in the initial release and to 11 in the 6.0 release. There a couple of great posts from William Lam and Mohammed Raffic that go through what each disk partition does. The big advantage in having these seperate partitions is that you can manage storage space a lot more granularly.

The problem as mentioned is that the underlying Linux file system is susceptible to storage issue. Not matter what storage platform you are running you are guaranteed to have issues at one point or another. In my experience Linux filesystems don’t deal will with those issues. Windows file systems seem to tolerate storage issue much better than their Linux counterparts and without starting a religious war I do know about the various tweaks that can be done to help make Linux filesystems more resilient to underlying storage issues.

With that in mind, the VCSA is very much susceptible to those same storage issues and I believe a lot of people are running into problems mainly triggered by storage related events. Most of the symptoms of the 503 relate back to key vCenter services unable to start after reboot. This usually requires some intervention to fix or a recovery of the VCSA from backup, but hopefully all that’s needed is to run an e2fsck against the filesystem(s) impacted.

The Solution:

VMware are putting a lot of faith into the VCSA and have done a tremendous job to develop it up to this point. It is the only option moving forward for VMware based platforms however there needs to be a little more work done into the resiliency of the services to protect against external issues that can impact the guest OS. PhotonOS is now the OS of choice from 6.5 onwards but that will not stop the legacy of susceptibility that comes with Linux based filesystems leading to issues such as the 503 error. If VMware can protect key services in the event of storage issues that will go a long way to improving that resiliency.

I believe it will get better and just this week VMware announced a monthly security patch program for the VCSA which shows that they are serious (not to say they where not before) about ensuring the appliance is protected but I’m sure many would agree that it needs to offer reliability as well…this is the one area where the Windows based vCenter has an advantage still.

With all that said, make sure you are doing everything possible to have the VCSA housed on as reliable as possible storage and make sure that you are not only backing up the VCSA and external dependancies correctly but understand how to restore the appliance including understanding of the inbuilt backup mechanisms for backing up the config and the PostGres database.

I love and would certainly recommend the VCSA…I just want to love it a little more without having to deal with possibility of having the 503 server error lurking around every storage event.

References:

http://www.vmwarearena.com/understanding-vcsa-6-5-vmdk-partitions-mount-points/

http://www.virtuallyghetto.com/2016/11/updates-to-vmdk-partitions-disk-resizing-in-vcsa-6-5.html

https://www.veeam.com/wp-vmware-vcenter-server-appliance-backup-restore.html

https://kb.vmware.com/kb/2091961

https://kb.vmware.com/kb/2147154

ESXI 6.5 Storage Performance Issues Resolved in Update 1

I originally came across the issue of slow storage performance with the native vmw_ahci driver that comes bundled with ESXi 6.5 just as I was first playing with my SuperMicro SYS-5028D-TN4T in my homelab. After publishing a couple of posts about the workaround shortly afterwards the issue become quiet prevalent in the community and the post continues to get decent traffic, meaning that the issues impacted quiet a few people out there.

The good news is that with the release of vSphere 6.5 Update 1 there is a fix for the problem in the form of updated drivers for the AHCI module. William Lam has been quick to blog about the fix and if you had previously disabled the driver you will need to re-enable it.

This VMwareKB covers the specific patch as listed in the release notes:

No confirmation as of yet if it actually does the trick, but the release notes look promising as the assumption is that it will resolve the issues so that homelabbers and people using the driver in production systems can rest easy.

References:

https://docs.vmware.com/en/VMware-vSphere/6.5/rn/vsphere-esxi-651-release-notes.html

https://kb.vmware.com/selfservice/microsites/search.do?language=en_US&cmd=displayKC&externalId=2149910

http://www.virtuallyghetto.com/2017/07/ahci-vmw_ahci-performance-issue-resolved-in-esxi-6-5-update-1.html

vSAN 6.6 – What’s In It For Service Providers

Last February when VMware released VSAN 6.2 I stated that “Things had gotten Interesting” with regards to the 6.2 release of vSAN finally marking it’s arrival as a serious player in the Hyper-converged Infrastructure (HCI) market. vSAN was ready to be taken very seriously by VMware’s competitors. Fast forward fourteen months and apart from the fact we have confirmed the v in vSAN is a lower case with the product name officially changing from Virtual SAN to vSAN…Version 6.6 was announced last week is set to GA today, and with it comes the biggest list of new features and enhancements in vSANs history.

VMware has decided to break with the normal vSphere release cycle for vSAN and move to patch releases for vSphere that are actually major updates of vSAN. This is why this release is labeled vSAN 6.6 and will be included in the vSphere 6.5EP2 build. The move allows the vSAN team to continue to enhance the platform outside of the core vSphere platform and I believe it will deliver at least 2 update releases per year.

Looking at the new features and enhancements of the vSAN 6.6 release it’s clear to see that the platform has matured and given the 7000+ strong customer base it’s also clear to see that its being accepted more and more for critical workloads. From a service provider point of view I know of a lot more vCloud Air Network partners that have implemented vSAN as not only their Management HCI platform, but also now their customer HCI compute and storage  platforms.

A lot for Service Providers to like:

As shown in the feature timeline above there are over 20+ new features and enhancements but for me the following ones are most relative to vCAN Service Providers who are using, or looking to use vSAN in their offerings. I will expand on the ones in red as I see them as being the most significant of the new features and enhancements for service providers.

  • Native encryption for data-at-rest
  • Compliance certifications
  • vSAN Proactive Drive HA for failing drives
  • Resilient management independent of vCenter
  • Rapid recovery with smart, efficient rebuilds
  • Certified file service & data protection solutions
  • Enhanced vSAN SDK and PowerCLI
  • Simple networking with Unicast
  • vSAN Cloud Analytics for performance
  • vSAN Cloud Analytics with real-time support notification and recommendations*
  • vSAN Config Assist with 1-click hardware lifecycle management
  • Extended Health Services
  • Up to 50% greater IOPS for all-flash with optimized checksum and dedupe
  • Optimized for latest flash technologies
  • Expanded caching tier choice
  • New Docker Volume Driver

Simple networking with Unicast:

As John Nicholson wrote on the Virtual Blocks blog…it’s time to say goodbye to the multicast requirements around vSAN networking traffic. For a history as to why multicast was used, click here. Also it’s worth reading John’s post and also the he goes through the upgrade process as if you are upgrading from previous versions, multicast will still be used unless you make the change as also specified here.

I can attest first hand to the added complexity when it comes to setting up vSAN with multicast and have gone through a couple of painful deployments where the multicast configuration was an issue during initial setup and also caused issue with switching infrastructure that needed to be upgraded to before vSAN could work reliably. In my mind unicast offers a simpler less complex solution with minimal overheads and makes it more transportable across networks.

Performance Improvements:

Service Providers are always trying to squeeze the most out of their hardware purchases and with VMware claiming 50% greater IOPS for all-flash through optimized data services that in theory can enable 150K IOPS per host it appears they will be served well. in addition to optimized checksum and dedupe along with support for the latest flash technologies. The increased performance helps accelerate tenant workloads and provides higher consolidation ratios for those workloads.

Service providers can accelerate new hardware technologies with the support of the latest flash technologies, including solutions like the new breed of NVMe SSDs. These solutions can deliver up to 250% greater performance for write-intensive applications. vSAN 6.6 now offers larger caching drive options that includes 1.6TB flash drives, so that service providers can take advantage of larger capacity flash drives.

Disk Performance Enhancements:

For those that have gone through a vSAN rebuild operation you would know that is can be a long exercise depending on the amount of data and configuration of the vSAN datastore. vSAN 6.6 introduces a new smart rebuild and rebalancing feature along with partial repairs of degraded or absent components. There is also resync throttling and improved visibility into the rebuilding status through the Health Status. Cormac Hogan goes through the improvements in detail here.

From a Service Provider point of view having these enhanced features around the rebuilds it critical to continued quality of service for IaaS customer who live on shared vSAN storage. Shorter and more efficient rebuild times means less impact to customers.

Health Checks and Monitoring Improvements:

vSAN Encryption:

VMware has introduced VM encryption native at the vSAN datastore level. This can be enabled per vSAN Cluster and works with deduplication and compression across hybrid and all-flash cluster configurations. vSAN 6.6 data Encryption is hardware agnostic, there is no requirement to use specialized and more expensive Self-Encrypting Drives (SEDs) which is also a bonus. Jase McCarty has another Virtual Blocks article here that goes through this feature in great detail.

From a Service Provider point of view you can now potentially offer two classes of vSAN backed storage for IaaS customers. One that lives on an Encrypted enabled cluster that’s charged at a premium over non Encrypted clusters. In talking with service providers across the globe, data at rest encryption has become something that potential customers are asking for and most leading storage companies have an encryption story…now so does vSAN and it appears to be market leading.

vSAN 6.6 Licensing:

In terms of the licensing Matrix, nothing too drastic has changed except for the addition of Data at Rest Encryption in the Enterprise bundle, however in a significant move for vCAN Service Providers, QoS IOPS Limiting has been extended across all license types and can now be taken advantage across the board. This is good for Service Providers who look to offer different tiers or storage performance based on IOPS limited…previously it was only available under Enterprise licensing.

Bootstrapping UI:

As a bonus feature that I think will assist vCAN Service Providers is the new Native Bootstrap installer in vSAN 6.6. William Lam has written about the feature here, but for those looking to install their first vSAN node without vSphere available the ability to bootstrap is invaluable. The old manual process is still worth looking at as it’s always beneficial to know what’s going on in the background, but it’s all GUI based now via the VCSA installer.

Conclusion:

vSAN 6.6 appears to be a great step forward for VMware and Service Providers will no doubt be keen to upgrade as soon as possible to take advantage of the features and enhancements that have been delivered in this 6.6 release.

References:

http://cormachogan.com/2017/04/11/whats-new-vsan-6-6/

https://storagehub.vmware.com/#!/vmware-vsan/vmware-vsan-6-5-technical-overview

http://vsphere-land.com/news/an-overview-of-whats-new-in-vmware-vsan-6-6.html

https://storagehub.vmware.com/#!/vmware-vsan/vsan-multicast-removal/multicast-removal-steps-and-requirements/1

vSAN 6.6 Encryption Configuration

vSAN 6.6 – Native Data-at-Rest Encryption

Goodbye Multicast

Native VCSA bootstrap installer in vSAN 6.6

ESXi 6.5 Storage Performance Issues and Fix

[NOTE] : I decided to republish this post with a new heading and skip right to the meat of the issue as I’ve had a lot of people reach out saying that the post helped them with their performance issues on ESXi 6.5. Hopefully people can find the content easier and have a fix in place sooner.

The issue that I came across was to do with storage performance and the native driver that comes bundled with ESXi 6.5. With the release of vSphere 6.5 yesterday, the timing was perfect to install ESXI 6.5 and start to build my management VMs. I first noticed some issues when uploading the Windows 2016 ISO to the datastore with the ISO taking about 30 minutes to upload. From there I created a new VM and installed Windows…this took about two hours to complete which I knew was not as I had expected…especially with the datastore being a decent class SSD.

I created a new VM and kicked off a new install, but this time I opened ESXTOP to see what was going on, and as you can see from the screen shots below, the Kernel and disk write latencies where off the charts topping 2000ms and 700-1000ms respectively…In throuput terms I was getting about 10-20MB/s when I should have been getting 400-500MB/s.

ESXTOP was showing the VM with even worse write latency.

I thought to myself if I had bought a lemon of a storage controller and checked the Queue Depth of the card. It’s listed with a QD of 31 which isn’t horrible for a homelab so my attention turned to the driver. Again referencing the VMware Compatibility Guide the listed driver for the controller the device driver is listed as ahci version 3.0.22vmw.

I searched for the installed device driver modules and found that the one listed above was present, however there was also a native VMware device drive as well.

I confirmed that the storage controller was using the native VMware driver and went about disabling it as per this VMwareKB (thanks to @fbuechsel who pointed me in the right direction in the vExpert Slack Homelab Channel) as shown below.

After the host rebooted I checked to see if the storage controller was using the device driver listed in the compatibility guide. As you can see below not only was it using that driver, but it was now showing the six HBA ports as opposed to just the one seen in the first snippet above.

I once again created a new VM and installed Windows and this time the install completed in a little under five minutes! Quiet a difference! Upon running a crystal disk mark I was now getting the expected speeds from the SSDs and things are moving along quiet nicely.

Hopefully this post saves anyone else who might by this, or other SuperMicro SuperServers some time and not get caught out by poor storage performance caused by the native VMware driver packaged with ESXi 6.5.


References
:

https://kb.vmware.com/selfservice/microsites/search.do?language=en_US&cmd=displayKC&externalId=2044993

Quick Look – vSphere 6.5 Storage Space Reclamation

One of the cool newly enabled features of vSphere 6.5 is the come back of VMFS storage space reclamation. This feature was enabled in a manual way for VMFS5 datastores and was able to be triggered when you free storage space inside a datastore when deleting or migrating a VM…or consolidate a snapshot. At a Guest OS level, storage space is freed when you delete files on a thinly provisioned VMDK and then exists as dead or stranded space. ESXi 6.5 supports automatic space reclamation (SCSI unmap) that originates from a VMFS datastore or a Guest OS…the mechanism reclaims unused space from VM disks that are thin provisioned.

When storage space is deleted without this automated feature the delete operation leaves blocks of unused space on the datastore. VMFS uses the SCSI unmap command to indicate to the array that the storage blocks contain deleted data, so that the array can unallocate these blocks.

On VMFS6 datastores, ESXi supports automatic asynchronous reclamation of free space. VMFS6 generally supports automatic space reclamation requests that generate from the guest operating systems, and passes these requests to the array. Many guest operating systems can send the unmap command and do not require any additional configuration. The guest operating systems that do not support automatic unmaps might require user intervention.

I was interested in seeing if this worked as advertised, so I went about formatting a new VMFS6 datastore with the default options via the Web Client as shown below:

Heading over the hosts command line I checked the reclamation config using the new esxcli namespace:

Through the Web Client you can only set the Reclamation Priority to None or Low, however through the esxcli command you can set that value to medium or high as well as low or none, but as I’ve literally just found out, these esxcli only settings don’t actually do anything in this release.

For the low setting in terms of reclaim priority and how long before the process kicks off on the datastore, the expectation is that any blocks that are no longer used will be reclaimed within 12 hours. I was keeping track of a couple of VMs and the datastore sizes in general and saw that after a day or so there was a difference in the available storage.

You can see that I clawed back about 22GB and 14GB on both datastores in the first 24 hours. So my initial testing with this new feature shows that it’s a valued and welcomed edition to the new vSphere 6.5 release. I know that for Service Providers that thin provision but charge based on allocated storage, they will benefit greatly from this feature as it automates a mechanism that was complex at best in previous releases.

There is also a great section around UNMAP in the vSphere 6.5 Core Storage White Paper that’s literally just been released as well and can be found here:

References:

http://pubs.vmware.com/vsphere-65/topic/com.vmware.ICbase/PDF/vsphere-esxi-vcenter-server-65-storage-guide.pdf

https://kb.vmware.com/selfservice/microsites/search.do?language=en_US&cmd=displayKC&externalId=2057513

vSphere 6.5 Core Storage White Paper Now Available

HomeLab – SuperMicro 5028D-TNT4 Storage Driver Performance Issues and Fix

Ok, i’ll admit it…i’ve had serious lab withdrawals since having to give up the awesome Zettagrid Labs. Having a lab to tinker with goes hand in hand with being able to generate tech related content…point and case, my new homelab got delivered on Monday and I have been working to get things setup so that I can deploy my new NestedESXi lab environment.
The issue that I came across was to do with storage performance and the native driver that comes bundled with ESXi 6.5. With the release of vSphere 6.5 yesterday, the timing was perfect to install ESXI 6.5 and start to build my management VMs. I first noticed some issues when uploading the Windows 2016 ISO to the datastore with the ISO taking about 30 minutes to upload. From there I created a new VM and installed Windows…this took about two hours to complete which I knew was not as I had expected…especially with the datastore being a decent class SSD.
By way of an quick intro (longer first impression post to follow) I purchased a SuperMicro SYS-5028D-TN4T that I based off this TinkerTry Bundle which has become a very popular system for vExpert homelabers. It’s got an Intel Xeon D-1541 CPU and I loaded it up with 128GB or RAM. The system comes with an embedded Lynx Point AHCI Controller that allows up to six SATA devices and is listed on the VMware Compatibility Guide for ESXi 6.5.

I created a new VM and kicked off a new install, but this time I opened ESXTOP to see what was going on, and as you can see from the screen shots below, the Kernel and disk write latencies where off the charts topping 2000ms and 700-1000ms respectivly…In throuput terms I was getting about 10-20MB/s when I should have been getting 400-500MB/s.

ESXTOP was showing the VM with even worse write latency.

I thought to myself if I had bought a lemon of a storage controller and checked the Queue Depth of the card. It’s listed with a QD of 31 which isn’t horrible for a homelab so my attention turned to the driver. Again referencing the VMware Compatability Guide the listed driver for the conrtoller the device driver is listed as ahci version 3.0.22vmw.

I searched for the installed device driver modules and found that the one listed above was present, however there was also a native VMware device drive as well.

I confirmed that the storage controller was using the native VMware driver and went about disabling it as per this VMwareKB (thanks to @fbuechsel who pointed me in the right direction in the vExpert Slack Homelab Channel) as shown below.

After the host rebooted I checked to see if the storage controller was using the device driver listed in the compatability guide. As you can see below not only was it using that driver, but it was now showing the six HBA ports as opposed to just the one seen in the first snippet above.

I once again created a new VM and installed Windows and this time the install completed in a little under five minutes! Quiet a difference! Upon running a crystal disk mark I was now getting the expected speeds from the SSDs and things are moving along quiet nicely.

Hopefully this post saves anyone else who might by this, or other SuperMicro SuperServers some time and not get caught out by poor storage performance caused by the native VMware driver packaged with ESXi 6.5.


References
:

http://www.supermicro.com/products/system/midtower/5028/SYS-5028D-TN4T.cfm

https://kb.vmware.com/selfservice/microsites/search.do?language=en_US&cmd=displayKC&externalId=2044993

Free Guide: Building NetApp ONTAP 9 Lab

In computing, there is one thing you shouldn’t compromise on…and that thing is storage. This carries over to Lab or NestedESXi environments as poor lab performance can be just as frustrating as production performance issues. I’ve used a number of nested storage platform’s for my lab environments and I’m always on the lookout for alternative solutions.

When Neil Anderson asked my to write a short introductory post on his new how-to guide Build Your Own NetApp ONTAP 9 Lab I decided to flick through the guide to check it out and see if it could add any value to my future plans for a homelab. The e-book is professionally laid out and has excellent diagrams, notes and step by step…it’s extremely comprehensive.

NetApp Simulator 9 Free eBook – Build Your Own NetApp ONTAP 9 Lab!

While I’ve never been a NetApp guy there does seem to be a level of complexity in the NetApp VSA setup, but with the step by step in the e-book any ambiguity is removed. If you are looking for lab storage this is a great end to end example of how to install and configure one based on ONTOP 9 NetApp Simulator.

Give it a look over here.

VSAN Upgrading from 6.1 to 6.2 Hybrid to All Flash – Part 3

When VSAN 6.2 was released earlier this year it came with new and enhanced features and with the price of SSDs continuing to fall and an expanding HCL it seems like All Flash instances are becoming more the norm and for those that have already deployed VSAN in a Hybrid configuration the temptation to upgrade to All Flash is certainly there. Duncan Epping has previously blogged the overview of migrating from Hybrid to All Flash so I wanted to expand on that post and go through the process in a little more detail. This is the final part of a three part blog series with the process overview outlined below.
