First Look: On Demand Recovery with Cloud Tier and VMware Cloud on AWS

Since Veeam Cloud Tier was released as part of Backup & Replication 9.5 Update 4, i’ve written a lot about how it works and what it offers in terms of offloading data from more expensive local storage to what is fundamentally cheaper remote Object Storage. As with most innovative technologies, if you dig a little deeper… different use cases start to present themselves and unintended use cases find their way to the surface.

Such was the case when, together with AWS and VMware, we looked at how Cloud Tier could be used as a way to allow on demand recovery into a cloud platform like VMware Cloud on AWS. By way of a quick overview, the solution shown below has Veeam backing up to a Scale Out Backup Repository which has a Capacity Tier backed by an Object Storage repository in Amazon S3. There is a minimal operational restore window set which means data is offloaded quicker to the Capacity Tier.

Once there, if disaster happens on premises, an SDDC is spun up, a Backup & Replication Server deployed and configured into that SDDC. From there, a SOBR is configured with the same Amazon S3 credentials that connects to the Object Storage bucket which detects the backup data and starts a resync of the metadata back to the local performance tier. (as described here) Once the resync has finished workloads can be recovered, streamed directly from the Capacity Tier.

The diagram above has been published on the AWS Reference Architecture page, and while this post has been brief, there is more to come by way of an offical AWS Blog Post co-authored by myself Frank Fan from AWS around this solution. We will also look to automate the process as much as possible to make this a truely on demand solution that can be actioned with the click of a button.

For now, the concept has been validated and the hope is people looking to leverage VMware Cloud on AWS as a target for disaster and recovery look to leverage Veeam and the Cloud Tier to make that happen.

References: AWS Reference Architecture

Veeam Availability Console v3 Important Patch Release

Today, a new patch was released for Veeam Availability Console v3 which brings the build to 3.0.0.2725. Contained in this patch is a number of fixes that covers reporting and licensing, server fixes, agent fixes and there are also a number of other resolved issues including some RESTful API fixes as well as for those using the ConnectWise Plugin. The patch is advised to be deployed to all VCSPs running Veeam Availability Console v3 in production.

To apply the patch, head to the VeeamKB here and follow the instructions. You need to have at least VAC v3 Build 3.0.0.2647 prior to installing as shown below.

From there, make sure you have a backup of the database, close down the Web UI and execute both MSI packages as administrator on the server.

The first one updates the VAC server. The second one updates the WebUI. Once completed the patches are applied and VAC v3 is up to date running on version number Server Version 3.0.0.2725.

References:

https://www.veeam.com/kb2960

Orchestration of NSX by Terraform for Cloud Connect Replication with vCloud Director

That is probably the longest title i’ve ever had on this blog, however I wanted to highlight everything that is contained in this solution. Everything above works together to get the job done. The job in this case, is to configure an NSX Edge automatically using the vCloud Director Terraform provider to allow network connectivity for VMs that have been replicated into a vCloud Director tenant organization with Cloud Connect Replication.

With the release of Update 4 for Veeam Backup & Replication we enhanced Cloud Connect Replication to finally replicate into a Service Providers vCloud Director platform. In doing this we enabled tenants to take advantage of the advanced networking features of the NSX Edge Services Gateway. The only caveat to this was that unlike the existing Hardware Plan mechanism, where tenants where able to configure basic networking on the Network Extension Appliance (NEA), the configuration of the NSX Edge had to be done directly through the vCloud Director Tenant UI.

The Scenario:

When VMs are replicated into a vCD organisation with Cloud Connect Replication the expectation in a full failover is that if a disaster happened on-premises, workloads would be powered on in the service provider cloud and work exactly as if they where still on-premises. Access to services needs to be configured through the edge gateway. The edge gateway is then connected to the replica VMs via the vOrg Network in vCD.

In this example, we have a LAMP based web server that is publishing a WordPress site over HTTP and HTTPs.

The VM is being replicated to a Veeam Cloud Service Provider vCloud Director backed Cloud Connect Replication service.

During a disaster event at the on-premises end, we want to enact a failover of the replica living at in the vCloud Director Virtual Datacenter.

The VM replica will be fired up and the NSX Edge (the Network Extension Appliance pictured is used for partial failovers) associated to the vDC will allow the HTTP and HTTPS to be accessed from the outside world. The internal IP and Subnet of the VM is as it was on-premises. Cloud Connect Replication handles the mapping of the networks as part of the replication job.

Even during the early development days of this feature I was thinking about how this process could be automated somehow. With our previous Cloud Connect Replication networking, we would use the NEA as the edge device and allow basic configuration through the Failover Plan from the Backup & Replication console. That functionality still exists in Update 4, but only for non vCD backed replication.

The obvious way would be to tap into the vCloud Director APIs and configure the Edge directly. Taking that further, we could wrap that up in PowerShell and invoke the APIs from PowerShell, which would allow a simpler way to pass through variables and deal with payloads. However with the power that exists with the Terraform vCloud Director provider, it became a no brainer to leverage this to get the job done.

Configuring NSX Edge with Terraform:

In my previous post around Infrastructure as Code vs APIs I went through a specific example where I configured an NSX Edge using Terraform. I’m not going to go over that again, but what I have done is published that Terraform plan with all the code to GitHub.

The GitHub Project can be found here.

The end result after running the Terraform Plan is:

  • Allowed HTTP, HTTPS, SSH and ICMP access to a VM in a vDC
    • Defined as a variable as the External IP
    • Defined as a variable as the Internal IP
    • Defined as a variable as the vOrg Subnet
  • Configure DNAT rules to allow HTTP, HTTPS and SSH
  • Configure SNAT rule to allow outbound from the vOrg subnet

The variables that align with the VM and vORG network are defined in the terraform.tfvars file and need to be modified to match the on-premises network configuration. The variables are defined in the variables.tf file.

To add additional VMs and/or vOrg networks you will need to define additional variables in both files and add additional entires under the firewall_rules.tf and nat_fules.tf. I will look at ways to make this more elegant using Terraform arrays/lists and programatic constructs in future.

Creating PowerShell for Execution:

The Terraform plan can obviously be run standalone and the NSX Edge configuration can be actioned at any time, but the idea here is to take advantage of the script functionality that exists with Veeam backup and replication jobs and have the Terraform plan run upon completion of the Cloud Connect Replication job every time it is run.

To achieve this we need to create a PowerShell script:

GitHub – configure_vCD_VCCR_NSX_Edge.ps1

The PowerShell script initializes Terraform and downloads the Provider, ensures there is an upgrade in the future and then executes the Terraform plan. Remembering that that variables will change within the Terraform Plan its self, meaning these scripts remain unchanged.

Adding Post Script to Cloud Connect Replication Job:

The final step is to configure the PowerShell script to execute once the Cloud Connect Replication job has been run. This is done via a post script settings that can be found in Job Settings -> Advanced -> Scripts. Drop down to selected ps1 files and choose the location of the script.

That’s all that is required to have the PowerShell script executed once the replication job completes.

End Result:

Once the replication component of the job is complete, the post job script will be executed by the job.

This triggers the PowerShell, which runs the Terraform plan. It will check the existing state of the NSX Edge configuration and work out what configuration needs to be added. From the vCD Tenant UI, you should see the recent tasks list modifications to the NSX Edge Gateway by the user configured to access the vCD APIs via the Provider.

Taking a look at the NSX Edge Firewall and NAT configuration you should see that it has been configured as specified in the Terraform plan.

Which will match the current state of the Terraform plan

Conclusion:

At the end of the day, what we have done is achieved the orchestration of Veeam Cloud Connect Replication together with vCloud Director and NSX… facilitated by Terraform. This is something that Service Providers offering Cloud Connect Replication can provide to their clients as a way for them to define, control and manage the configuration of the NSX edge networking for their replicated infrastructure so that there is access to key services during a DR event.

While there might seem like a lot happening, this is a great example of leveraging Infrastructure as Code to automated as otherwise manual task. Once the Terraform is understood and the variables applied, the configuration of the NSX Edge will be consistent and in a desired state with the config checked and applied on every run of the replication job. The configuration will not fall out of line with what is required during a full failover and will ensure that services are available if a disaster occurs.

References:

https://github.com/anthonyspiteri/automation/tree/master/vccr_vcd_configure_nsx_edge

The Reality of Disaster Recovery Planning and Testing

As recent events have shown, outages and disasters are a fact of life in this modern world. Given the number of different platforms that data sits on today, we know that disasters can equally come in many shapes and sizes and lead to data loss and impact business continuity. Because major wide scale disasters occur way less often than smaller disasters from within a datacenter, it’s important to plan and test cloud disaster recovery models for smaller disasters that can happen at different levels of the platform stack.

Because disasters can lead to revenue, productivity and reputation loss, it’s important to understand that having cloud based backup is just one piece of the data protection puzzle. Here at Veeam, we empower our cloud and service providers to offer services based on Veeam Cloud Connect Backup and Replication. However, the planning and testing of what happens once disaster strikes is ultimately up to either the organizations purchasing the services or the services company offering Disaster Recovery as a Service (DRaaS) that is wrapped around backup and replication offerings.

Why it’s Important to Plan:

In theory, planning for a disaster should be completed before selecting a product or solution. In reality, it’s common for organizations to purchase cloud DR services without an understanding of what needs to be put in place prior to workloads being backed up or replicated to a cloud provider or platform. Concepts like recovery time and recovery point objectives (RTPO) need to be understood and planned so, if a disaster strikes and failover has occurred, applications will not only be recovered within SLAs, but also that data on those recovered workloads will be useful in terms of its age.

Smaller RTPO values go hand-in-hand with increased complexity and administrative services overhead. When planning ahead, it’s important to size your cloud disaster platform and build the right disaster recovery model that’s tailored to your needs. When designing your DR plan, you will want to target strategies that relate to your core line of business applications and data.

A staged approach to recovery means that you recover tier-one applications first so the business can still function. A common tier-one application example is the mail server. Another is payroll systems, which could result in an organization being unable to pay its suppliers. Once your key applications and services are recovered, you can move on to recovering data. Keeping mind that archival data generally doesn’t need to be recovered first. Again, being able to categorize systems where your data sits and then working those categories into your recovery plan is important.

Planning should also include specific tasks and controls that need to be followed up on and adhered to during a disaster. It’s important to have specific run books executed by specific people for a smoother failover. Finally, it is critical to make sure that all IT staff know how to accessing applications and services after failover.

Why it’s Important to Test:

When talking about cloud based disaster recovery models, there are a number of factors to consider before a final sign-off and validation of the testing process. Once your plan is in place, test it regularly and make adjustments if issues arise from your tests. Partial failover testing should be treated with the same level of criticality as full failover testing.

Testing your DR plan ensures that business continuity can be achieved in a partial or full disaster. Beyond core backup and replication services testing, you should also test networking, server and application performances. Testing should even include situational testing with staff to be sure that they are able to efficiently access key business applications.

Cloud Disaster Recovery Models:

There are a number of different cloud disaster recovery models, that can be broken down into three main categories:

  • Private cloud
  • Hybrid cloud
  • Public cloud

Veeam Cloud Connect technology works for hybrid and public cloud models, while Veeam Backup & Replication works across all three models. The Veeam Cloud & Service Provider (VCSP) program offers Veeam Cloud Connect backup and replication classified as hybrid clouds offering RaaS (recovery-as-a-service). Public clouds, such as AWS and Azure, can be used with Veeam Backup & Replication to restore VM workloads. Private clouds are generally internal to organizations and leverage Veeam Backup & Replication to replicate or back up or for a backup copy of VMs between datacenter locations.

The ultimate goal here is to choose a cloud recovery model that best suits your organization. Each of the models above offer technological diversity and different price points. They also plan and test differently in order to, ultimately, execute a disaster plan.

When a partial or full disaster strikes, a thoroughly planned and well-tested DR plan, backed by the right disaster recovery model, will help you avoid a negative impact on your organization’s bottom line. Veeam and its cloud partners, service-provider partners and public cloud partners can help you build a solution that’s right for you.

First Published on veeam.com by me – modified and updated for republish today

Veeam Powered Network v2 Azure Marketplace Deployment

Last month Veeam PN v2 went GA and was available for download and install from the veeam.com download page. As an update to that, we published v2 to the Azure Marketplace which is now available for deployment. As a quick refresher, Veeam PN was initially released as part of Direct Recovery to Azure and was marketed through the Azure Marketplace. In addition to that, for the initial release I went through a number of use cases for Veeam PN which are all still relevant with the release of v2:

With the addition of WireGuard replacing OpenVPN for site-to-site connectivity the list of use cases will be expanded and the use cased above enhanced. For most of my own use of Veeam PN, I have the Hub living in an Azure Region which I connect up into where ever I am around the world.

Now that the Veeam PN v2 is available from the Azure Marketplace I have created a quick deployment video that can be viewed below. For those that want a more step by step guide as a working example, you can reference this post from v1… essentially the process is the same.

  • Deploy Veeam PN Appliance from Azure Marketplace
  • Perform Initial Veeam PN Configuration to connect Azure
  • Configure SiteGateway and Clients

NOTE: One of the challenges that we introduced by shifting over to WireGuard is that there is no direct upgrade path from v1 to v2. With that, there needs to be a side by side stand up of v2 and v1 to enable a configuration migration… which at the moment if a manual process.

References:

https://anthonyspiteri.net/veeam-powered-network-azure-and-remote-site-configuration/

Cloud Tier Deep Dive Super Session On Demand!

Last week at VeeamON 2019, Dustin Albertson and myself delivered a two part deep dive session on Cloud Tier, which was released in Update 4 of Veeam Backup & Replication 9.5 in January. I’ve blogged about how Cloud Tier is one of the most innovative features i’ve seen in recent times and I have been able to dig under the covers of the technology from early in the development cycle. I have presented basic overviews to more complex deep dives over the past six or so months however at VeeamON 2019, Dustin and myself took it a step further and went even deeper.

Part I:

The first part of the Deep Dive was presented as the first session of the event, just after the opening keynote. It was on main stage and was all slide driven content that introduces the Cloud Tier, talks about the architecture and then dives deeper into its inner workings as well as us talking about some of the caveats.

Part II:

From the first session to the last session slot of the event…to finish up, Dustin and I presented a demo only super session which I have to admit… was one of the best sessions i’ve ever been a part of in terms of flow, audience participation and what we where able to actually show. We even where able to show off some of the new COPY functionality coming in v10.

There are a few scripts that we used in that session that I will look to release on GitHub over the next week or so.. so stay tuned for those! But for now, enjoy the session recordings embedded above.

VeeamON 2019 – Highlighting theCUBE Show Wrap

Hard to believe that another VeeamON has come and gone… for us in the Product Strategy Team the lead up and the week is immensely busy… but this is what we live and breath for! Everyone came away from the conference extremely pleased with how it panned out and we believe it also was a success based on what we heard coming out of media, analysts and the general IT community through social media.

In this post, I want to comment on a great Show Wrap from theCUBE hosted by Dave Vallante and Peter Burris which I think highlights exactly where Veeam is currently placed (Act I)… and where we are going in the industry (Act II).

Veeam is not about bragging rights and lots of flashy announcements…

This is a great quote from theCUBE Show Wrap (video embedded below) which speaks to what we at Veeam are trying to achieve. We are not restrained by the pressures of potential IPOs and we are confident enough to continue to be aggressive in the market while delivering on our core values of Simplicity, Reliability and Flexibility.

To comment a little more around what was talked about in theCUBE show wrap; It was interesting to hear perspective from the hallways about how people where talking about solving problems… Veeam is creating opportunities to solve problems with the focus on the customer. That is what successful companies focus on!

The messaging that theCUBE talked about from what they saw at the event was that Veeam is all about Data Protection across wherever your data lives… Backup is where is starts! Veeam still believes this and is focused…while not over rotating on the larger vision. Lots of their competitors are going hard after data management… modern architecture… Veeam is not legacy, but growing… if not flourishing due to the focus it has.

It’s a big, complex market and everyone is going to fight hard for it. Focused R&D is a very important concept to focus on… Veeam isn’t looking to be everything to everyone which can result in a wide but potentially shallow feature set. We see this with our newer competition… the concept of fast iterative development can have its flaws and though at times we don’t release as often as others in the market, when we do release new features and enhancements they are focused and reliable… you only need to look at the Cloud Tier that came as part of Update 4 for Backup & Replication 9.5.

Veeam has done a great job of keeping their finger on the Pulse… Veeam has done a good job of navigating what can customers really do (around data protection) and not getting too far ahead.

It’s all about our ecosystem and who we partner with… giving our customers the freedom of choice through our agnosticity. If we can nail the ecosystem partnership and make it seamless then Dave Vallante believe that Veeam has the advantage moving forward. This is where our Veeam Cloud Data Protection Platform centred around Backup & Replication and our Storage APIs will come into play.

Veeam is taking an almost Apple like approach…give customer what they can handle… then give them a little bit more.

Some really interesting thoughts in the Show Wrap from beginning to end… it’s worth a watch and I believe backs up the general feeling of a VeeamON show well executed which backs our shift into Act II.

This tweet sums it up well:

The whole stream of what was recorded at VeeamON 2019 by theCube can be found here:

VeeamON 2019 – Mainstage Technical Session Recap and Video

Hard to believe that another VeeamON has come and gone… for us in the Product Strategy Team the lead up and the event itself is immensely busy, but this is what we live and breath for! Everyone came away from the conference extremely pleased with how it panned out and we believe it also was a success based on what we heard coming out of media, analysts and the general IT community through social media.

We did something a little different this year at VeeamON. Instead of having one long General Session Keynote, we split the general sessions into two parts… one being a Veeam Vision keynote delivered by Ratmir in the morning, and the second being a Technology General Session held later in the day.

The idea was to dedicate ninety minutes to showcase what we had released already in 2019 and then, take an advanced look at what was to come later in the year. The other thing that we wanted to achieve was bring back to the live demos to the VeeamON mainstage as we saw in 2015 and in 2017.

Session Breakdown:

It’s pretty rare in our industry for companies to attempt live demos during keynote presentations… the ghosts of Microsoft BSODs past seem to hinder the use of live demos these days, but that is not how Veeam and the Veeam Product Strategy Team rolls. To pull off 8 live demos without a glitch (4 of which running on Tech Preview code) is a testament to the confidence we have in ourselves and in the technology… it’s also a huge rush when everything comes off as expected.

That said, the Technology General Session is worth watching for those interested in what Veeam has delivered so far this year… and what is to come!

Released : Veeam PN v2…Making VPNs Simple, Reliable and Scalable

When it comes to connecting remote sites, branch offices or extending on-premises networks to the cloud that level of complexity has traditionally always been high. Networking has always been the most complex part of any IT platform. There has also always been a high level of cost associated with connecting sites…both from a hardware or a software point of view. There are also the man hours to ensure things are setup correctly and will continue to work. As well and that, security and performance are also important factors in any networking solution..

Simplifying Networking with Veeam

At VeeamOn in 2017, we announced the release candidate for Veeam Powered Network (Veeam PN) which in combination with our Restore to Azure functionality created a new solution to ease the complexities around extending an on-premises network to an Azure network to ensure connectivity during restoration scenarios. In December of that year, Veeam PN went generally available as a FREE solution.

What Veeam PN does well is present a simple and intuitive Web Based User Interface for the setup and configuration of site-to-site and point-to-site VPNs. Moving away from the intended use case, Veeam PN became popular in the IT enthusiast and home lab worlds as a simple and reliable way to remain connected while on the road, or to mesh together with ease networks that where spread across disparate platforms.

By utilizing OpenVPN under the surface and automating and orchestrating the setup of site-to-site and point-to-site networks, we leveraged a mature Open Source tool that offered a level of reliability and performance that suited most use cases. However, we didn’t want to stop there and looked at ways in which we could continue to enhance Veeam PN to make it more useful for IT organizations and start to look to increase underlying performance to maximize potential use cases.

Introducing Veeam Powered Network v2 featuring WireGuard®

With the release of Veeam PN v2, we have enhanced what is possible for site-to-site connectivity by incorporating WireGuard into the solution (replacing OpenVPN for site-to-site) as well as enhancing usability. We also added the ability to better connect to remote devices with the support of DNS for site-to-site connectivity.

WireGuard has replaced OpenVPN for site-to-site connectivity in Veeam PN v2 due to the rise of it in the Open Source world as a new standard in VPN technologies that offers a higher degree of security through enhanced cryptography and operates more efficiently, leading to increased performance and security. It achieves this by working in kernel and by using fewer lines of code (4000 compared to 600,000 in OpenVPN) and offers greater reliability when thinking about connecting hundreds of sites…therefore increasing scalability.

For a deeper look at why we chose WireGuard… have a read of my offical veeam.com blog. The story is very compelling!

Increased Security and Performance

By incorporating WireGuard into Veeam PN we have further simplified the already simple WireGuard setup and allow users of Veeam PN to consume it for site-to-site connectivity even faster via the Veeam PN Web Console. Security is always a concern with any VPN and WireGuard again takes a more simplistic approach to security by relying on crypto versioning to deal with cryptographic attacks… in a nutshell it is easier to move through versions of primitives to authenticate rather than client server negotiation of cipher type and key lengths.

Because of this streamlined approach to encryption in addition to the efficiency of the code WireGaurd can out perform OpenVPN, meaning that Veeam PN can sustain significantly higher throughputs (testing has shown performance increases of 5x to 20x depending on CPU configuration) which opens up the use cases to be for more than just basic remote office or homelab use. Veeam PN can now be considered as a way to connect multiple sites together and have the ability to transfer and sustain hundreds of Mb/s which is perfect for data protection and disaster recovery scenarios.

Other Enhancements

The addition of WireGuard is easily the biggest enhancement from Veeam PN v1, however there are a number of other enhancements listed below

  • DNS forwarding and configuring to resolve FQDNs in connected sites.
  • New deployment process report.
  • Microsoft Azure integration enhancements.
  • Easy manual product deployment.
Conclusion

Once again, the premise of Veeam PN is to offer Veeam customers a free tool that simplifies the traditionally complex process around the configuration, creation and management of site-to-site and point-to-site VPN networks. The addition of WireGuard as the site-to-site VPN platform will allow Veeam PN to go beyond the initial basic use cases and become an option for more business-critical applications due to the enhancements that WireGuard offers.
